EDGECAM - Advanced CAM for Production machining
Features at a glance
Edgecam seamlessly Integrates with mainstream CAD Software such as Solidworks, Autodesk Inventor, Solid Edge, Creo to name but a few as standalone CAM system, whilst offering users an easy to use Graphical interface and intuitive dialogues making programming simple for first time users with full control for more advanced tool path requirements.
Comprehensive 2.5 Axis to full 5 Axis Simultaneous Milling is fully Supported.
Complex Mill/Turn Components and Machine Tools are taken care of with ease with full support from 2 Axis Turning to Advanced Multiple Turret, B Axis with twin Spindle Support and up to 6 axis Machining centers . Edgecam’s Wire EDM CAM solution provides you with the flexibility and confidence to manufacture 2 and 4 axis parts accurately and efficiently. Complete the process with on-Machine measuring using Edgecam Probing and Inspection functionality.
Post Processing
EDGECAM Milling Systems
Essential Milling
2.5 Axis milling
Suitable for Companies with 3 axis Machining centers but the components being manufactured do not require full 3 axis CNC milling functionality. Edgecam has a wide range of milling and drilling options available to get those parts programmed fast. Visualize the complete machining process in Edgecam CAM Simulator with full machine simulation. Have peace of mind to get the part machined efficiently, while saving on setup time and tooling costs.
Take your Prismatic programming to another level with our Edgecam solid machinist add-on module and automate your programming using Strategy Manager
Add- on modules to get more out of your system
Standard Milling
Full 3 axis with 4th axis Rotary and positional and 5 axis Positional capability.
Suitable for Vertical or Horizontal 4 or 5 Axis Machining Centers. This is the most popular Edgecam module to get the most out of you Machine Tool from the get go. With a full suite of hole options available, Edgecam’s efficient Waveform Roughing strategies and 3 axis finishing toolpaths, Edgecam exploits the productivity of single setups on 4/5 axis CNC machines.
Add- on modules to get more out of your system
- Solid Machinist and Strategy Manager
- Automatic multiple parts setup
- 4 Axis Simultaneous machining
- Probing and inspection
Advanced Milling
Support for Angled head attachments and Secondary Z/ Quill Axis.
Adding to the 3 axis capability of Standard CNC Milling module, Edgecam Advanced CNC milling Includes support for Deep Hole Drilling, Plunge Roughing and opens up a broader range of 3 axis Surface / free-form finishing toolpaths. Adding to this, more advanced machine configurations are supported such as Angle head Attachments and Quill axis.
Add- on modules to get more out of your system
- Solid Machinist and Strategy Manager
- Automatic multiple parts setup
- 4/5 Axis Simultaneous machining
- Probing and inspection
Ultimate Milling
Complete suite of Edgecam Surface finishing Toolpaths.
Building on the functionality and capability of the Advanced CNC Milling Module, open up the complete suite of Edgecams excellent Mold & Die 3 axis finishing Cycles to achieve Optimum surface finish on freeform components.
Add- on modules to get more out of your system
EDGECAM Turning Systems
Essential Turning
2 Axis Turning.
Suitable for 2 Axis Vertical or Horizontal CNC Lathes with a Single Turret and Single Spindle. Tailstock and steady rest support with support for all Tool Types. Advanced Functionality for all 2 axis Turning applications whether they are large or small components, Hard or Soft materials. With Edgecam Essential CNC Lathe you have complete control over the production process. With full machine Simulation in Edgecam CAM Simulator, avoid unwanted collisions and Setup time.
Add- on modules to get more out of your system
Standard Turning
2 axis CNC Lathe with CY axis Milling Capability.
This module will suite Vertical or Horizontal CNC Lathe Centres, Single Spindle and Single Turret Machines with Live Tooling / Milling Capability. Machine those components you have never been able too because of limited programming capability at the machine Control. Edgecams Standard CNC Lathe Module will offer capability to machine complex Components with advanced and efficient toolpaths including Edgecam Waveform Turning technology, saving you machine time, setup time and Tooling Costs.
Add- on modules to get more out of your system
Advanced Turning
Suitable for Turn/Mill Multi-Task Machine Tools. Support for Twin Turret, Single or twin Spindle CNC Machines. Machines with B axis Capability is fully Supported.
In a collision rich environment, Edgecam Advanced CNC Lathe will give you peace of mind when programming complex components. Optimize machining time with a full range of Turning and Milling Toolpath options available, Ensure you are getting the best Cycle time possible on your machine with full Turret Synchronization, and flexible Part transfer options.
Add- on modules to get more out of your system
Ultimate Turning
Multi -Turret Twin Spindle Solution.
Edgecam Ultimate CNC Lathe Module offers a Complete Turning Solution for Complex Multitask Machine Tools. Support for Up to 4 Turrets, dual Spindles and B axis Support. Full Turret Synchronisation to optimise Turret working time. Have peace of mind programming complex parts with full CNC machine Simulation and extensive toolpath functionality for all types of applications and tool types.
Add- on modules to get more out of your system
EDGECAM WIRE EDM
Wire EDM
Software for Comprehensive Programming of all Wire EDM Machine Tools.
Edgecam’s Wire EDM solution provides you with the flexibility and confidence to manufacture 2 and 4 axis parts accurately and efficiently. Advanced functionality enables manufacture of complex shapes with irregular tapers with ease. Extensive Post processors and Cutting technology databases.
Add- on modules to get more out of your system
Solid Machinist and Strategy Manager
EDGECAM Production Systems
Essential Production
All round Solution for Milling machine Tools and 2 axis CNC Lathe centres
Edgecam Essential Production is the complete Solution comprised of the functionality of the Essential CNC Milling and Essential CNC Lathe Modules described. Program your 3 axis CNC Milling centres and 2 axis CNC Lathe/Turning centres with a cost effective Bundled CNC Software Solution.
– See Essential Turning and Essential milling functionality above.
Add- on modules to get more out of your system
Standard Production
CNC Milling and CNC Lathe Software for programming your 3/4/5 Axis Machining centres and CNC Mill/Turn & CNC Lathe centres
Edgecam Standard Production is the complete Solution comprised of the functionality of the individual Standard CNC Milling and Standard CNC lathe Modules described. Program your 3/4/5 axis Machining centres and Mill/Turn Turning centres with a cost effective Bundled CNC Software Solution.
– See Standard Turning and Standard milling functionality above.
Add- on modules to get more out of your system
Advanced Production
Advanced Machining Bundle for Multi Task CNC Lathe and up to 5 Axis Machining centres
Edgecam Advanced Production is the complete Solution comprised of the functionality of the individual Advanced CNC Milling and Advanced CNC Lathe Modules described. Program your 3/4/5 axis Machining centres and Multitask Turning centres with a cost effective Bundled CNC Software Solution.
– See Advanced Turning and Advanced milling functionality above.
Add- on modules to get more out of your system
Ultimate Production
Penultimate Software for 5 axis Positional Machining centres and Multi Turret Multi-task CNC Mill/Turn Turning Centres
Edgecam Ultimate Production is the complete Solution comprised of the functionality of the individual Ultimate CNC Milling and Ultimate CNC Lathe Modules described. Program your 3/4/5 axis Machining centres and Multi Turret Multi task Turning centres with a cost effective Bundled CNC Software Solution.
– See Ultimate Turning and Ultimate milling functionality above.
Add- on modules to get more out of your system
