EDGECAM Add on Modules
Unlock the Full Power of EDGECAM with Advanced Machining Add-On Modules
Enhance productivity and precision with EDGECAM modules designed for CNC programming automation and reduced setup time. Each module extends capability—whether it’s for advanced 5-axis machining, mill-turn operations, feature recognition, or automated programming, these additional modules significantly enhance your machining processes.
Edgecam add-on modules to increase and improve capabilty
Features at a glance
Enhance productivity and precision with EDGECAM modules designed to automate CNC programming and reduce setup time. Each module extends capability—whether it’s advanced machining with 5-axis or 6-axis machining, mill-turn operations, feature recognition, or support for complex machine configurations. The additional EDGECAM modules give you the confidence to take on more complex jobs.
Scalable and flexible, EDGECAM grows with your business, delivering faster CNC programming, consistent quality, and maximum machine utilization for a smarter, more profitable workshop.
Solid Machinist and strategy Manager
Standalone CAD Software interface and knowledge-based machining are essential for advanced machining processes. Within Edgecam, the integrity of your design is maintained because any native solid model from mainstream CAD software vendors, including Autodesk Inventor, Solidworks, Solid Edge, Creo, Unigraphics NX, and CATIA, is imported without translation. Edgecam Solid Machinist utilizes automatic feature recognition to analyze the solid model, quickly identifying machinable features for CNC programming. Edgecam then offers users the most appropriate tooling and machining strategy to generate accurate toolpaths.
Building on this solid foundation, Edgecam Strategy Manager enhances productivity through fast and reliable machining of solid models. This application streamlines programming by capturing knowledge from previously machined parts and applying it to new components, effectively eliminating programming errors and delivering an unprecedented level of consistency and automation through its various Edgecam modules.
Probing
Advanced machining processes, particularly complex CNC machining operations, can now be easily validated with in-process probing. Manufacturers producing high-value parts can quickly and efficiently develop probe paths and integrate measurement cycles with CNC programming. EDGECAM modules offer a comprehensive set of geometric features and constructions for measuring part characteristics such as webs, pockets, thickness, and heights. The intuitive user interface and workflow allow users to seamlessly transition from programming CAM cycles to measurement cycles.
Probe Compatibility: Supports any type of touch probe.
Probe Movement:
Protected moves ensure safe positioning.
Probe trigger during movement → Emergency Stop and error.
Probing Cycles & Functions:
Probe Corner
Probe Bore/Boss
Probe Web/Pocket
Probe Surface
Probe 4th Axis
Probing Functional Outputs:
Update Work Coordinate.
Measure
Tool correction
EDGECAM provides the ability to create custom masks specific to the probe system requirements of your probing cycles.
Multiple parts machining
Automate multiple parts programming with the EDGECAM Tombstone Manager, enhancing your advanced machining capabilities. Utilize the entire envelope of your machine tool, whether it’s a 3-axis, horizontal, or 5-axis machining center. With the power of EDGECAM modules, you can add any number of components or various operations to your setup, whether it's on the bed of a 3-axis machine, a tombstone fixture for a horizontal machining center, or a pyramid-type fixture for a 5-axis machine tool. Maintain full toolpath associativity to the individually programmed single parts while optimizing tool usage and the CNC programming process.
Edgecam 4 and 5 axis Machining
Software for advanced machining with full 4 and 5 axis Continuous Machining
Edgecam offers a wide range of 4 and 5 axis strategies applicable to solid and surface geometry, making it a leader in CNC programming.
Edgecam’s 4 axis strategies are ideal for the rotary machining of automotive and aerospace components such as camshafts, crankshafts, and blades, as well as for the production of rotary dies and components in the oil & gas industry.
With Edgecam 5 Axis Simultaneous, you can improve surface finish and extend tool life by orienting the tool to maintain optimum contact with the part at all times. This approach provides improved access to undercuts and deep pockets by tilting the tool or component, enabling the use of shorter series tooling and eliminating the need for secondary setups. The 5 axis tool paths can result in significant movements of the machine tool, even from very small cuts on the component. Such movements can potentially cause severe damage to both the part and the machine. Edgecam effectively provides methods for collision avoidance, checking the cutter and holder for potential collisions and applying necessary tilts to steer clear of collision areas.
The Edgecam Advanced 5 Axis module offers total control of 4 and 5 axis tool paths using solids, surfaces, or wireframe geometries. This advanced machining module includes additional functionality beyond the standard 5 axis capabilities and is particularly suited for complex components such as blings, blisks, and port machining, where precise control of tool paths and entry and exit paths is crucial.
Probing and Inspection
EDGECAM Inspect is an intuitive, fully integrated on-machine measurement solution designed for fast, reliable creation of inspection and probing cycles directly within the CAM environment, making it a crucial tool for advanced machining. It enables users to validate machining operations, measure complex geometries, and generate professional inspection reports — all from a single workflow, enhancing CNC programming efficiency.
Combining Hexagon’s metrology expertise and PC-DMIS fit libraries, EDGECAM Inspect ensures accurate, consistent, and standards-compliant measurement results. Its feature recognition tools simplify programming, allowing multiple part features to be defined and measured with a single click — including points, circles, planes, webs, pockets, and orientations.
Users can seamlessly switch between machining and measurement operations to validate processes, perform in-process or final inspections, and visualize results with color-coded deviation feedback on the CAD model. Offline simulation and flexible tolerancing further enhance efficiency in advanced machining tasks.
Advanced probe calibration algorithms maintain precision in multi-axis setups, while GD&T tools allow deeper analysis of circularity, cylindricity, and flatness without removing the part from the CNC machine.
In short: EDGECAM Inspect streamlines programming, probing, and reporting — uniting machining and measurement in one powerful, easy-to-use CAM environment that saves time, improves quality, and boosts productivity across all EDGECAM modules.
Advanced Multitasking
Software Solution for Advanced Machining with Rotary Turning Tools on Horizontal Machine Tools. Advanced Multi-Task allows you to define and utilize Rotary Turning tools on large horizontal machine tools like the Trevisan, enhancing your CNC programming capabilities through integrated EDGECAM modules.
Additive and Hybrid Manufacturing
Additive Manufacturing Software for Hybrid Machine Tools
The Edgecam Additive Module enables companies to adapt to new hybrid machine tools by facilitating an advanced machining process where material deposition is applied. This module supports a variety of cycles, including up to 5-axis capabilities, allowing companies to add material and subsequently machine it to size using standard CNC programming methods, commonly referred to as subtractive processes. By combining these innovative techniques, companies can fully leverage their machine tools' capabilities with the help of EDGECAM modules.
Specialist Systems
Inspection System
EDGECAM Inspect is a standalone inspection software dedicated to providing users with a fully featured inspection interface that facilitates post machining on machine inspection. This advanced machining solution combines industry-leading metrology tools and know-how from Hexagon Manufacturing Intelligence with cutting-edge manufacturing expertise.
The EDGECAM Inspection system is an intuitive, fully integrated on-machine measurement solution designed for fast and reliable creation of inspection and probing cycles. It enables users to validate machining operations, measure complex geometries, and generate professional inspection reports — all within a single workflow.
By leveraging Hexagon’s metrology expertise and PC-DMIS fit libraries, EDGECAM Inspect ensures accurate, consistent, and standards-compliant measurement results. Its feature recognition tools simplify CNC programming, allowing multiple part features to be defined and measured with a single click — including points, circles, planes, webs, pockets, and orientations.
Users can seamlessly produce a final on-machine inspection and visualize results with color-coded deviation feedback on the CAD model. Offline simulation and flexible tolerancing further enhance efficiency.
Advanced probe calibration algorithms maintain precision in multi-axis setups, while GD&T tools allow for deeper analysis of circularity, cylindricity, and flatness without needing to remove the part from the CNC machine.
In short, EDGECAM Inspect streamlines programming, probing, and reporting — uniting machining and measurement in one powerful, easy-to-use environment that saves time, improves quality, and boosts productivity, making it an essential tool among EDGECAM modules.
Shopfloor Editor
Just in time Program Editing with Edgecam Shop Floor Editor empowers machinists on the shop floor to efficiently load Edgecam part files and make quick adjustments to a limited number of parameters in the machining sequence. This advanced machining solution allows users to run the Simulator and generate a new NC file with ease. Ideal for making minor edits like feed rates and spindle speeds without altering the toolpath trajectory itself, this capability reduces the reliance on the programming office for small modifications that can be effectively handled right at the machine using EDGECAM modules.
WorkXPlore
High Speed Collaborative CAD Viewer
WorkXplore is the ideal tool for directly displaying and evaluating 3D CAD Software files without the need for the original CAD Software application. This advanced CAD solution features an intuitive, easy-to-use interface that allows both novice and experienced users to explore and visualize any type of 2D/3D CAD Software file. Users can analyze designs and collaborate effectively, making it a perfect fit for advanced machining projects, especially those involving CNC programming. By utilizing WorkXplore, teams can save time before committing resources to creating a real prototype, enhancing productivity in their workflow and optimizing the use of EDGECAM modules.
Our design, scanning & Virtual machine simulation solutions
DESIGNER
Handheld scanners
DESIGNER
True CAD for CAM now supports advanced machining techniques, incorporating direct modelling for seamless design. With easy model repair, advanced surfacing, and precise electrode design, users can enhance their CNC programming capabilities. Additionally, our tools facilitate reverse engineering and sheet metal work, making the most of the EDGECAM modules available.
NCSIMUL
Handheld scanners
DESIGNER
CAM Neutral provides advanced machining capabilities with its real CNC 'Digital Twin' feature. This includes fast G code validation and precise G-Code simulation, which are essential for effective CNC programming. Additionally, the system offers tool length optimization and toolpath optimization, making it ideal for lights out manufacturing. The integration of EDGECAM modules further enhances these processes.
Handheld scanners
Handheld scanners
Handheld scanners
The advanced machining solutions we offer emphasize portability and ease of use, ensuring high performance for users. By integrating CNC programming with EDGECAM modules, we provide a significant productivity boost. Our innovative technology is designed to be versatile, seamlessly fitting into smart manufacturing integration.
