NCSIMUL Machine

From fixture design, to part repair & modification, Edgecam Designer is the ultimate CAD software solution for taking geometry through to manufacture. Using Direct Modelling techniques the user is freed from the constraints of a traditional modelling system. Rather than modifying a lengthy series of parameters to make a design change. Direct modelling gives the user complete freedom of construction whether creating a new component or modifying an existing design created in any of the myriad of CAD formats that Designer supports.

Edgecam Designer is the perfect Solution for Model Healing, Feature Suppression and Model Simplification, not to mention new component design. Edgecam Designer supports the import of DXF and DWG files allowing the user to transform existing 2D data into a 3D model by simply reusing the imported profiles from the original data.



    NCSIMUL Machine

    From fixture design, to part repair & modification, Edgecam Designer is the ultimate CAD software solution for taking geometry through to manufacture. Using Direct Modelling techniques the user is freed from the constraints of a traditional modelling system. Rather than modifying a lengthy series of parameters to make a design change. Direct modelling gives the user complete freedom of construction whether creating a new component or modifying an existing design created in any of the myriad of CAD formats that Designer supports.

    Edgecam Designer is the perfect Solution for Model Healing, Feature Suppression and Model Simplification, not to mention new component design. Edgecam Designer supports the import of DXF and DWG files allowing the user to transform existing 2D data into a 3D model by simply reusing the imported profiles from the original data.



      You may be interested in :

      Edgecam Solid Machinist

      Edgecam WorkXPlore

      Edgecam Probing

      Edgecam Inspection

      You may be interested in these Add ons :

      Add-on – Multiple Parts Programming

      Add-on – 4 Axis Simultaneous milling

      Add-on – 5 Axis Simultaneous milling

      You may be interested in :

      CAD Interface to NCSimul

      CAM Interface to NCSimul

      NCDOC

      NCSIMUL OPTITOOL

      NCSIMUL 4 CAM

      NCSIMUL Probing

      Videos:

      Design Capability

      Freeform surface design as well as 3D wireframe design with IGES, VDA-FS, DXF and DWG file loaders.

      Machining Capability.

      Multi Axis 4 axis Turning (X and Z axis on Upper and Lower Turrets) Sub-spindle support. C and Y axis Milling capability on Main and Sub spindle.

      Toolpathing Options

      Turning

      Rough Turning Functionality

      • Canned Cycle Support
      • In Process Stock Support (The Cycle respects Material left from previous machining operations)
      • Variable Machine Attributes (Variable Speeds / Feeds and material allowance on different areas of a nominal Design part)
      • Cut Strategies (Standard, Sectioned Toolpath,Ramp and variable cut depth)
      • Cutter Compensation
      • Waveform Turning
      • Variable approach Types (In / Out)
      • Collision avoidance for Chuck and Tailstock

      Finish Turning Functionality

      • Canned Cycle Support
      • Variable machine Attributes (As per Rough Turning)
      • Cutter Compensation
      • Corner Types Control (Break Radius and Chamfer – On components without the geometry contained in the design,Edgecam can control break radius’s / Chamfers within the cutter path
      • Automatic down Cutting
      • Various approach Types (In /Out)

      Rough Grooving Functionality

      • Standard Cycle includes 4 Types (Sequential, Centre Sequential,Centre Alternate and Castellation)
      • Peck Grooving Support
      • Rough Side Grooving with Lace and Constant Cut Types
      • Side Force Correction
      • Deep Grooving

      Finish Grooving Functionality

      • Cutter Comp Support
      • Offset Side Front / Back of Insert
      • Profile overlap
      • Split at Centre

      Screw Cutting Functionality

      • Canned Cycle Support
      • Multiple Start Support
      • Degression
      • Support for various tool shapes

            – Holes: Full range of Hole cycles for Fixed Drilling with Canned Cycle support

            Milling Functionality:- C,Y and B axis indexing and Milling

            -Rough Milling Functionality :

      • 3D roughing for wireframe, surface and solid models with automatic multi-tool rest roughing and intermediate slices.
      • Automatic Fixture Avoidance
      • Traditional Roughing Strategies include Spiral, Concentric and Lace with Trochoidal milling options.
      • Edgecam Waveform Strategy
      • Automatic Flat Land Detection
      • Multiple approach types with Speed and feed variation when entering material.
      • In  Process Stock Support as well as machining from 3D Rough stock.
      • Detection of Undercut Stock
      • Adaptive Feedrates

      Plunge Roughing

            Finishing Cycles Functionality:

      •  Profiling :
      • 3D Profile finishing with helical option
      • Profile 3D Curves
      • Cusp Height Control
      • Rest Profiling (Auto detect uncut areas)
      • Finish Shallow areas (Constant Cusp)
      • Undercut machining
      • Automatic Fixture Avoidance
      • Auto-Detect Solid model for collision avoidance
      • Multiple Passes with Spring Cuts
      • Cutter Compensation Support
      • Adjust Feedrates on Arc movements
      • Various Corner Strategies, including break Chamfer and Break radius (this gives added functionality to break corners without design model changes)
      • Automatic Flatland detection
      • Optimised Link movements control



      Project Toolpaths (Advanced Suface Finishing Operations)

      • Project Toolpath (Project any 2D Toolpath onto 3D Surface)
      • Project Boundry Collapse (Pattern of finish Toolpath determined by shape of profile boundry to project onto 3D Surface)
      • Project Circular (Specific Toolpath for circular surface geometry
      • Project Flow Curves (Pattern of toolpath determined by curves to follow)

               -Pencil Milling

               -Flow Surface finishing Cycle

      • Undercut Support



      Flatland Finishing

      • Lace, Concentic and Finish Pass Strategies
      • Rest Flat land (Will detect Flate areas of Uncut material from previous larger tools)



      Parrallel Lace Finishing

      • 3 axis Simultaneous Cycle
      • Automatic Flat areas exclusion
      • Output Point to point, Line Arc Smooth or Spline



      Thread Milling

      • Canned Cycle Support
      • Cutter Compensation Support
      • Adjust Feedrate to Contact point
      • Multiple Start Option
      • Multiple passes and Spring Cuts Support
      • Optimise path Control



      Engraving

      • Strategies include,Clear Floor (embossing) ,Finishing (Inside geometry with Ramp movements in Sharp Corners & Centreline (Will detect Centreline geometry of Font Geometry)
      • Project onto 3D Surfaces

      Chamfering

      • Dedicated Chamfer or Deburring options
      • Cutter Compensation Support
      • Automatic detection of chamfers from Solid Model Features
      • 3D Chamfering / Deburring
      • Automatic detection of Sidewalls for collision avoidance

      Slotting

      • 2D and 3D Slot
      • Ramp Slotting

                 -Holes:

      • Full Range of hole cycles (Multi-level,multi-depth) & canned cycle,
      • Back Boring
      • Support for Deep-Hole Drilling
      • Planar (Linear) and Rotary (Angular) mode output.



      Standard in all Edgecam Systems:

      • Edgecam Technology assistant: linked tools and Materials for automatic calculation of speeds and feeds.
      • Edgecam Toolkit assistant: Maintain control of tools available on shopfloor and machines and used for specific jobs
      • Edgecam Toolstore: Tool library complete with list of Standard tooling and also easy functionality for creating new and special tools.
      • Edgecam Job Manager: Have complete control over Jobs and Projects and maintain communication with key areas in the Workshop and design office. Print detailed setup sheets for Programmers and have database of CAD file, CAM file and NC file.



      Edgecam Code Wizard: Easily create and edit Post Processors using the Code Wizard in the easy to use Interface
